JL-24 Air Powered Cleat Folder
- Manufacturer:
- J and L Machinery
- Condition:
- NEW
- Machine Location:
- F.O.B Factory
Em-Pro Closed End Pneumatic Cleat Folders are strengthened by changes resulting from 25 years of dealing directly with customer feedback, to produce a machine that can handle a variety applications with virtually no adjustment required. Problems with odd shaped, or specialty fittings are a thing of the past. With four option packages available, coupled with the ability to produce custom units, we can handle nearly any situation our customers may encounter.
- Bend Length: 3, – 24,
- Capacity: 20GA Mild Steel or lighter
- Table Height: 36
- Table Depth: 21-1/2
- Heat Treated Bending Bar & Backgauge Fingers: Yes
- Back Gauge Depth: 7/16, or 1/2, FIXED (Must specify with order)
- Bend Angle Options: 180 degree
- Air Requirements: 90-100 PSI, 4-5 Sec/cycle
- Air Consumption: < 0.5 cu ft/cycle at 100 P. S. I.
- Weight: 800 lbs
Em-Pro Closed End Pneumatic Cleat Folders are strengthened by changes resulting from 25 years of dealing directly with customer feedback, to produce a machine that can handle a variety applications with virtually no adjustment required. Problems with odd shaped, or specialty fittings are a thing of the past. With four option packages available, coupled with the ability to produce custom units, we can handle nearly any situation our customers may encounter.
- Bend Length: 3, – 24,
- Capacity: 20GA Mild Steel or lighter
- Table Height: 36
- Table Depth: 21-1/2
- Heat Treated Bending Bar & Backgauge Fingers: Yes
- Back Gauge Depth: 7/16, or 1/2, FIXED (Must specify with order)
- Bend Angle Options: 180 degree
- Air Requirements: 90-100 PSI, 4-5 Sec/cycle
- Air Consumption: < 0.5 cu ft/cycle at 100 P. S. I.
- Weight: 800 lbs
